Full-scale drift harmonic suspension kit NEW RELEASE

New release of full-scale drift harmonic suspension kit!

Based on CUSCO SPORT R / TN_R, reset to drift specification.







Semi-custom order is possible.

Can be change the stroke such as damping force and spring rate according to vehicle specifications.











Two types of coilovers are available.
1 Way (SPORTS R)
2 Way (SPORT TN_R)
Semi-custom order is possible.
Can be change the stroke such as damping force and spring rate according to vehicle specifications.







"1WAY/24-step adjustment coilover"

Special design for drift
New design by tilting rear bush adjusting for low height and rear positive camber.
Reducing stress on bushes and dampers and enabling smooth strokes.
SPORT R for DRIFT/1WAY/24-step adjustment coilover
Now available(BTO)

TOYOTA MarkⅡ, Chaser, Cresta)JZX90 /JZX100)
1WAY/24-step adjustment coilover
upper mount
Front:camber fixed / pillow
Rear:camber fixed / pillow
Recommended height adjustment range: Front -60~0mm Rear -60~-15mm
Reference vehicle height:Front -40mm Rear -50mm
Maximum vehicle height adjustment range:Front -80~0mm Rear -90~-15mm
Spring standard rate: Front 065-200-24kgf/mm Rear 065-250-5kgf/mm
Spring option rate:Front (26/28kgf/mm) Rear(4/6/7/8kgf/mm)


Nissan Silvia, 180SX
【SPORT R for DRIFT】
Nissan Silvia, 180SX(S13/PS13/RPS13)
1WAY/24-step adjustment coilover
upper mount
Front:camber fixed / pillow
Rear:camber fixed / pillow
Recommended height adjustment range: Front -60~0mm Rear -65~-25mm
Reference vehicle height:Front -35mm Rear -35mm
Maximum vehicle height adjustment range:Front -95~0mm Rear -100~-25mm
Spring standard rate: Front 065-200-8kgf/mm Rear 065-250-5kgf/mm
Spring option rate:Front (7/9/10kgf/mm) Rear (4/6/7/8kgf/mm)
【SPORT R for DRIFT】
Nissan Silvia S14
1WAY/24-step adjustment coilover
upper mount
Front:camber fixed / pillow
Rear:camber fixed / pillow
Recommended height adjustment range: Front -50~0mm Rear -65~0mm
Reference vehicle height:Front -30mm Rear -30mm
Maximum vehicle height adjustment range:Front -95~0mm Rear -120~0mm
Spring standard rate: Front 065-200-8kgf/mm Rear 065-250-5kgf/mm
Spring option rate:Front (7/9/10kgf/mm) Rear (4/6/7/8kgf/mm)
Option: Can be changed to camber caster adjustable pillow upper mount(add¥20,000)
【SPORT R for DRIFT】
Nissan Silvia S15
1WAY/24-step adjustment coilover
upper mount
Front:camber fixed / pillow
Rear:camber fixed / pillow
Recommended height adjustment range: Front -55~0mm Rear -65~0mm
Reference vehicle height:Front -35mm Rear -35mm
Maximum vehicle height adjustment range:Front -80~0mm Rear -120~0mm
Spring standard rate: Front 065-200-8kgf/mm Rear 065-250-5kgf/mm
Spring option rate:Front (7/9/10kgf/mm) Rear (4/6/7/8kgf/mm)
Option: Can be changed to camber caster adjustable pillow upper mount(add¥20,000)








"2WAY/24-step adjustment coilover"

【SPORT TN_R for DRIFT】
TOYOTA MarkⅡ, Chaser, Cresta)JZX90 /JZX100)
1WAY/24-step adjustment coilover
upper mount
Front:camber fixed / pillow
Rear:camber fixed / pillow
Recommended height adjustment range: Front -60~0mm Rear -60~15mm
Reference vehicle height:Front -40mm Rear -50mm
Maximum vehicle height adjustment range:Front -80~0mm Rear -90~-15mm
Spring standard rate: Front 065-200-24kgf/mm Rear 065-250-5kgf/mm
Spring option rate:Front (26/28kgf/mm) Rear(4/6/7/8kgf/mm)
【SPORT TN_R for DRIFT】
Nissan Silvia, 180SX(S13/PS13/RPS13)
1WAY/24-step adjustment coilover
upper mount
Front:camber fixed / pillow
Rear:camber fixed / pillow
Recommended height adjustment range: Front -60~0mm Rear -65~25mm
Reference vehicle height:Front -35mm Rear -35mm
Maximum vehicle height adjustment range:Front -95~0mm Rear -100~-25mm
Spring standard rate: Front 065-200-8kgf/mm Rear 065-250-5kgf/mm
Spring option rate:Front (7/9/10kgf/mm) Rear (4/6/7/8kgf/mm)
Option: Can be changed to camber caster adjustable pillow upper mount(add¥20,000)
【SPORT TN_R for DRIFT】
Nissan Silvia S14
1WAY/24-step adjustment coilover
upper mount
Front:camber fixed / pillow
Rear:camber fixed / pillow
Recommended height adjustment range: Front -50~0mm Rear -65~0mm
Reference vehicle height:Front -30mm Rear -30mm
Maximum vehicle height adjustment range:Front -95~0mm Rear -120~0mm
Spring standard rate: Front 065-200-8kgf/mm Rear 065-250-5kgf/mm
Spring option rate:Front (7/9/10kgf/mm) Rear (4/6/7/8kgf/mm)
Option: Can be changed to camber caster adjustable pillow upper mount(add¥20,000)
【SPORT TN_R for DRIFT】
Nissan Silvia S15
1WAY/24-step adjustment coilover
upper mount
Front:camber fixed / pillow
Rear:camber fixed / pillow
Recommended height adjustment range: Front -55~0mm Rear -65~0mm
Reference vehicle height:Front -35mm Rear -35mm
Maximum vehicle height adjustment range:Front -80~0mm Rear -120~0mm
Spring standard rate: Front 065-200-8kgf/mm Rear 065-250-5kgf/mm
Spring option rate:Front (7/9/10kgf/mm) Rear (4/6/7/8kgf/mm)
Option: Can be changed to camber caster adjustable pillow upper mount(add¥20,000)
The recommended vehicle height adjustment range is base on the date which developed by our company.
Please note that we are not responsible for any use beyond the recommended vehicle height.
